Neptune DBFC-5 5-Gallon Cartridge Filter Bypass Feeder

The Neptune DBFC-5 is a high-capacity, dual-purpose vessel designed for industrial and commercial water treatment systems. This 5-gallon unit serves as both a high-pressure bypass feeder for chemical shot-feeding and a side-stream filtration housing. It is the ideal solution for larger closed-loop chilled water, hot water, and process loops where simultaneous chemical treatment and sediment removal are essential.

Integrated Chemical Dosing and Filtration The DBFC-5 features an internal core specifically engineered to hold a Neptune filter cartridge. By combining these two functions, the DBFC-5 eliminates the need for a separate filter housing, saving valuable floor space in mechanical rooms. This "two-in-one" system ensures that as chemicals are introduced to treat the water, the side-stream is continuously filtered to remove suspended solids that can cause erosion or scale buildup on heat exchange surfaces.

Technical Specifications:

• Capacity: 5 Gallons

• Maximum Pressure: 300 PSI

• Design: Dome Bottom with Integrated Steel Legs

• Internal Core: Compatible with standard Neptune replacement filter cartridges

• Closure: 4-inch Threaded Easy-Access Opening

• Origin: Made in USA

Built for High-Pressure Environments: Constructed from heavy-duty carbon steel and rated for 300 PSI, the DBFC-5 is designed for long-term durability in demanding HVAC and industrial settings. The wide 4-inch threaded closure allows for rapid filter cartridge changes and safe chemical additions without the need for specialized tools, reducing maintenance time and improving operator safety.
